TesterMeter-SH-ADS-ABC Groveed Type Photoelectronic Switch
TECHNICAL SPECIFICATION
Model | SLUR-ADSC-2SCOC-B |
Supply Voltage | DC11V～30V±5% |
Current Consumption | <40mA |
Detection Method | Projective |
Detected Distance | 23mm |
Detected Object | Opaque object more than 5mm |
Detection Channel | Single channel |
Light Source | Infrared Emitting Diode （940nm） |
Response Frequency | >1KHz（<1ms） |
Protective Circuit | Power reverse connection protection；Overcurrent and overvoltage protect circuit outout |
Control Output | Load supply voltage Max:30VDC; Load current Max:120mA (the remaining voltage Max:1VDC); |
Indicator Lamp | Power Indicator: Green LED Action Indicator: Red LED; (Dark-Light) |
Voltage Withstand | 500VAC 50/60Hz 1min |
Ambient Lighting | Incandescent lamp：<3000Lux； Sunlight：<10000Lux |
Ambient Temperature | Work: -20℃～65℃； Storage: -35℃～70℃ |
Ambient Humidity | Work: 35～80%RH； Storage: 35～80%RH |
Insulation Resistance | Min：20MΩ（500VDC） |
Vibration Resistance | 10～55Hz Amplitude fluctuation 1.5m X、Y、Z each direction 2h |
Impact Resistance | 500m/s2 X、Y、Z each direction 2h |
IP Code | IP54 |
Material | ABS |
Weight | About 60g |
Cable Length | Default is 2M, which can be customized according to client's requirements |
Certification | CE、UCMP、ISO：9001 |
