Testermeter-ETCR ETB256 NETD 40mK Thermal Camera 256x192 IR 25Hz Frame Rate for Mechanical Inspection Handheld Infrared Thermal Imager

  • Main Feature :
  • Serial No. : Lisa0845
Contact Us For QuotationEmail:  464560351@qq.comWhatsapp&Wechat:+8618620373879

Testermeter-ETCR ETB256 NETD 40mK Thermal Camera 256x192 IR 25Hz Frame Rate for Mechanical Inspection Handheld Infrared Thermal Imager

Product descriptions

Product Function
Real-time image observation, temperature analysis and other functions can be performed.
Product Features
1. -20°C ~ 550°C temperature measurement range, 3 temperature measurement units can be switched.
2. 6 color palettes to choose from, 4 image modes to choose from, 16G built-in storage.
3. Flashlight function, rechargeable battery.
Technical Specification
Model
ETB160
ETB256
Infrared resolution
160×120
256×192
Pixel size
17μm
12μm
Focal length of thermal imaging lens
3.2mm
3.5mm
Spatial resolution/IFOV
5.31mrad
3.43mrad
Instrument weight
About 396g (including battery)
About 394g (including battery)
Body size
231mm×79mm×85mm
Detector type
Vanadium oxide (VOx) microbolometer
Infrared response
band 8～14μm
Frame rate
25Hz
Thermal sensitivity/NETD
≤40 mK(@25℃,F#1.0)
Focus mode
Focus-free
Field of view
0° × 37.2°
Measuring range
-20℃～550℃
Temperature measurement accuracy
±2℃ or ±2% of reading, whichever is greater
Temperature measurement resolution
0.1℃
Temperature measurement mode
Industrial temperature measurement
Temperature measurement unit
℃/℉/K
Temperature measurement display
Center point/highest point/lowest point temperature measurement
Image mode Infrared mode
visible light mode, fusion mode, picture-in-picture mode
Image/video format
JPEG/MP4
Photo/Video Recording
Support
Language Supports
10 languages
Storage
16G
Data Interface
Type-C
Battery
3200mAh (non-removable)
Charging Time
≤4h
Total Power
≤1.6W
Working Time
≥6h
Working Temperature
-10～50℃
Working Humidity
10%～90%RH non-condensing
Storage Temperature
-20～60℃
IP Rating
IP54
Certification
CE, FCC, ROHS
Random Accessories
Instrument: 1; Charging Cable: 1; Lanyard: 1

图片关键词图片关键词图片关键词




Lable: ETCR ETB256
