Product Introduction
| Hioki benchtop battery testers support simultaneous high-speed measurement in the ever-expanding production lines of increasingly larger lithium-ion low resistance batteries. The BT4560 battery impedance tester measures the impedance of lithium-ion batteries using the low-frequency AC-IR measurement method without charging and discharging the battery, substantially reducing the time needed to inspect the internal resistance of battery cells. |
Main Features
● Low-frequency AC-IR measurement (*1): Measure the reaction resistance of a battery ● Extremely reliable measurements for low-impedance batteries (*2) ● Circuit configuration highly tolerant of contact and wire resistance to provide stable measurements ● Voltage measurement function equivalent to 6-digit DMM (± 0.0035% rdg.)
|
Basic specification
sAccuracy guaranteed: 1 year
| Allowable input voltage | Up to 5 V | |||||
|---|---|---|---|---|---|---|
| Measured information | Impedance, voltage, temperature | |||||
| Impedance measurement | Parameters: R, X, Z, θ, Frequency: 0.1 Hz to 1050 Hz, Measurement ranges: 3.0000 mΩ, 10.0000 mΩ, 100.000 mΩ Testing current: 3 mΩ range: 1.5 Arms, 10 mΩ range: 500 mArms, 100 mΩ range: 50 mArms | |||||
| Voltage measurement | Measurement range: 5.00000 V (single range), Measurement time: 0.1 s (Fast) to 1.0 s (Slow) | |||||
| Temperature measurement | Range: -10.0 °C to 60.0 °C, Measurement time: 2.3 s | |||||
| Basic accuracy | Z: ±0.4% rdg. θ: ±0.1 °, V: ±0.0035% rdg. ±5 dgt. , Temperature: ±0.5 °C (at 10.0 to 40.0 °C) | |||||
| Functions | Comparator, self-calibration, sample delay, average, contact check, measurement current error, and other | |||||
| Interfaces | RS-232C/USB (virtual COM port) * Cannot be used simultaneously EXT. I/O (NPN/PNP can be switched) | |||||
| Power supply | 100 to 240 V AC, 50/60 Hz, 80 VA max | |||||
| Dimensions and mass | 330 mm (12.99 in) W × 80 mm (3.15 in) H × 293 mm (11.54 in) D, 3.7 kg (130.5 oz) | |||||
| Included accessories | Power cord ×1, Instruction manual ×1, Zero-adjustment board ×1, USB cable (A-B type) ×1, CD-R (communication instruction manual, PC application software, USB driver) ×1 | |||||
